zxsp – the Sinclair ZX Home Computers Simulator

screenshot2s.jpg zxsp is a simulator for the historic Sinclair ZX home computer family for Mac OS X. The current version only supports Intel-Macs. Versions for Mac OS Classic, PowerPC and old versions of Mac OS X are available from the Old versions/ directory.

screenshot1s.jpg zxsp simulates the black&white models ZX80 and ZX81, the Jupiter Ace, the ZX Spectrum models with 16K and 48K ram, the Spanish clone from Inves, the +128, +2, the +2A/+2B and the +3 including the Spanish and French localised versions, the Portuguese TC2048 and the TS2068-based machines TS2068 (USA), TC2068 (Portugal) and unipolbrit 2086 (Poland). If you still own one of the emulated machines and find that the simulation does not match the original, you are welcome to contact me for further improvement. Just keep the original thing ready for testing. :-)

zxsp can load from and save to a built-in virtual tape recorder or a real-world cassette recorder or a real-world computer. It also can dup real-world cassette tapes to ".tap" and ".tzx" files or vice versa.

Space Invaders for ZX80.gif zxsp supports ".sna", ".z80" and ".ace" snapshot files, ".tap", ".tzx", ".80", ".81", ".o", ".p", ".wav", ".aiff" tape files, ".dsk" disc files, ".dck" TCC dock files, ".img", ".dmg", ".iso" and ".hdf" hard disc images, ".scr" and ".gif" animated screenshots, excellent sound, precise screen and border effects, joysticks, a virtual tape recorder and virtual keyboards.

SoundTracker-1.gif zxsp comes with a debugger with register edit for the main chips and various memory display modes, a video beam position indicator, single stepper and memory disassembly. The machine can be throttled down to 1 Hz or overdrived to 20 MHz cpu clock. You can directly load Z80 assembler sources into zxsp or you can use zasm for assembling. The built-in assembler is a spawn of zxsp, so you may want to look into the zasm documentation anyway.

Runs on ...

zxsp runs on Intel Macs with Mac OS X 10.6 (Snow Leopard) and above. Reportedly it also runs well on M1 ARM based Macs with Mac OS 13.1 (Ventura) under emulation. Here you find snapshots of the current state of development. Scroll to the end of this page to find the downloads. Versions for Mac OS Classic, PowerPC and old versions of Mac OS X are available from the Old versions/ directory.

Feature Summary

as of 2023-02-16 for version 0.8.30 beta

Supported machines:
Features:
Supported file formats:
Supported real-world machinery:
Supported virtual peripherals:
Integrated debugger:

What's new

2015-05-18: Version 0.8.0.pre27: Emulation of Romantic Robots' Multiface ONE, 128 and +3
2018-2022 : Version 0.8.0.pre28: Play & record .rzx files. Improved Currah µSpeech accuracy.
2023-02-16: Version 0.8.28 beta: Perfect ZX80 & ZX81 timing and video emulation.
2023-03-02: Version 0.8.29 beta: First public release after 8 years
2023-03-07: Version 0.8.32 beta: fixed crash at start when in and out audio sample frequencies didn't match
2023-03-11: Version 0.8.33 beta: internal refactoring, some fixes

Please note: Version 0.8.28 beta and later now have some bugs. If you need a stable version please stick to 0.8.0pre27. Please report bugs at zxsp/issues.

Git Repository

github.com/Megatokio/zxsp

The Old Blog

Blog at blogspot.com

The Files:

Name Letzte Änderung Länge
Documentation/ 2019-11-18 19:27 40
Examples/ 2019-08-20 05:23 25
Old versions/ 2023-03-05 10:09 10
Screenshots/ 2023-02-01 16:40 68
2012-12-07 Debugger.png
size: 1700 × 1051
2012-12-07 22:13 824237
size: 348 × 209
2012-12-22 19:20 41391
size: 513 × 115
2012-12-22 19:20 39814
2013-05-21 plus2 tape recorder.png
size: 280 × 257
2013-05-21 13:39 37891
2013-06-09 SPECTRA Interface.png
size: 848 × 698
2013-06-09 18:04 271298
2013-06-12 SPECTRA interface.png
size: 764 × 528
2013-06-12 18:10 248263
2013-10-19 Lenslok - Colossal.png
size: 640 × 480
2013-10-18 18:48 53417
2013-11-23 TC2086 Dock with Cartridge.jpg
size: 333 × 268
2013-11-23 17:28 40648
2014-04-01 DivIDE interface.png
size: 402 × 318
2014-04-01 16:15 187733
2015-04-26 Currah µSpeech.jpg
size: 322 × 258
2015-04-26 18:37 38165
2015-05-18 MF128.png
size: 428 × 332
2015-05-18 17:56 124451
zxsp-0.8.0.pre26.zip 2015-04-26 18:58 17437861
zxsp-0.8.0.pre27.zip 2015-05-18 17:58 17522252
zxsp-0.8.32-beta-fixed.zip 2023-03-07 16:48 17955479
zxsp-0.8.33-beta-debug.zip 2023-03-11 17:56 18310110
zxsp-0.8.33-beta.zip 2023-03-11 17:53 18059890
